mipi video splicing-凯发官网入口

release time2022-07-14

system description: input video with two cameras and 1 mipi csi, use ef2 device for video splicing, and output the video to cpu via one mipi csi.

system requirements:

(1) a total of 7 pairs of mipi ios with two mipis for input and one mipi for output.

(2) up to 3 i2cs are required for sensor configuration, totaling 6 ios.

(3) internal memory is required for more flexible image stitching and conversion.

ip requirements:

(1) csi-2 rx , csi-2 tx

(2) i2c master, i2c slave

recommended for fpga
