product brief

ef3 devices are the third generation of the “elf” series launched by anlogic infotech.

ef3 devices are based on 55 nm low-power technology and feature optimized power consumption and performance, delivering high functionality at low cost. positioned in the communications, industrial control and server markets, the product supports up to 336 i/os to meet customer board-level io expansion application requirements.

contact sales

product table

find 4 results

dffs	luts	distributeram	eram-9k	eram-totalbrambits	m18*18	pll	user io	user flash	package methods	package size
4800	4800	38k	15	135k	8	2	280	8mb	cabga324	15*15
9280	9280	74k	30	270k	16	2	336	8mb	cabga400	17*17
11776	11776	94k	68	620k	0	2	383	8mb	cabga484	19x19
11776	11776	94k	68	620k	0	2	475	8mb	cabga642	23*23

product features
application scenarios
materials download

product features

flexible logical structure

logic scales from 1.5k to 10k luts, supporting up to 475 user ios
built-in flash

built-in 8mb flash, no external device required
enhanced security design

each chip has a unique 64-bit dna

application scenarios
